High Pressure (1.75MPa)
Performance Table
Standard discharge rate and required power at 1450 min-1 (50Hz)
Model / Specifications | Discharge Rate (L/min) | Required Power (W) | ||||||||
---|---|---|---|---|---|---|---|---|---|---|
Pressure (MPa) | Pressure (MPa) | |||||||||
0.35 | 0.7 | 1.05 | 1.4 | 1.75 | 0.35 | 0.7 | 1.05 | 1.4 | 1.75 | |
3611A | 35.1 | 35 | 34.8 | 34.6 | 34.5 | 314 | 596 | 878 | 1161 | 1474 |
3610A | 32.4 | 32.3 | 32.1 | 31.9 | 31.8 | 314 | 565 | 847 | 1129 | 1443 |
3609A | 29.2 | 29.1 | 28.9 | 28.8 | 28.6 | 314 | 533 | 816 | 1067 | 1255 |
3608A | 25.9 | 25.7 | 25.6 | 25.4 | 25.3 | 282 | 471 | 722 | 941 | 1129 |
3607A | 23 | 22.9 | 22.7 | 22.6 | 22.4 | 282 | 439 | 627 | 847 | 1098 |
3606A | 19.7 | 19.5 | 19.4 | 19.2 | 19.1 | 251 | 408 | 596 | 784 | 972 |
3605A | 16 | 15.9 | 15.7 | 15.6 | 15.4 | 220 | 345 | 533 | 722 | 910 |
